Automatic Paint Roller Frame Handle Making Machine is used to produce steel wire paint roller frame handles fully automatically. It can not only make lips stamping but also threading and end chamfering fully automatically. Paint Roller Frame Handle Making Machine adopts PLC control system and 7 Inch Touch screen. By chaning different mold, we can make different size paint roller frame handle. CNC operation is simpler and easier to learn than the same type of PLC products. Generally, the simple program can be edited by oneself within half an hour with elementary school education. Because all the servo motors are used, there will be no hydraulic failure, the failure rate is lower, the scrubbing is more convenient, and the pollution caused by oil pollution will not occur.
Automatic Paint Roller Frame Handle Making Machine Product
Specification of Automatic Paint Roller Frame Handle Making Machine
| Model | RM-PR-8S | RM-PR-8RS | RM-PR-8MU | RM-PR-4 |
| Function | chamfering | chamfering +threading | overdue long type | pin punching |
| Wire Diameter | 3-8mm | 3-8mm | 3-8mm | 1.5-4mm |
| Feeding Length | 0-500mm | 0-500mm | 0-900mm | 0-500mm |
| Production Capacity | 15pcs per minute | 12pcs per minute | 12pcs per minute | 25-30pcs per minute |
| Power | 5.5kw | 5.5kw | 5.5kw | 5.5kw |
| Dimension | 230*127*192cm | 230*127*192cm | 245*127*195cm | 180*120*178cm |
| Weight | 1300kg | 1350kg | 1400kg | 1100kg |
Working Video of Paint Roller Frame Making Machine with Threading Function
Company Profile
Romiter Machinery Co., Ltd. is a market-leading designer and a manufacturer of brush machinery. we focused on researching and designing the machinery for different types of brush manufacture solutions. Now, Our factory can provide wooden paint brush handle forming machine, automatic wooden brush ferrule nailing machine, Wooden Brush Handle Round Forming Machine, Wooden Paint Brush Handle Surface Shaving Machine, Wooden Brush Handle Hole Drilling Machine, Paint Brush Wooden Handle Sanding Machine, Brush Bristle Mixing Machine, Brush Ferrule Bristle Filling Machine, cosmetic wooden brush handle machine, Paint Roller Frame Handle Making Machine, Paint Roller Brush Making Machine, Paint Roller Frame Cage Assembling Machine, paint roller frame handle assembling machine, toothbrush making machine and brush metal ferrule making machine.
Romiter Brush Processing Machine meets Europe Quality Requirement. with CE Certification
Welcome to contact us for more information.
