Automatic Round Handle Bamboo Toothbrush Production Line is used to make round shape bamboo toothbrush handle brush from raw bamboo. it mainly includes bamboo sawing machine, bamboo set-size shaving machine, bamboo plate stick set-size cutting machine, CNC type bamboo toothbrush handle round shape forming machine, bamboo toothbrush handle hole drilling machine and bamboo toothbrush hair planting machine
1. Automatic Bamboo Square Stick Production Line
| Item | Name | Power | Weight | Size(mm) |
| 1 | Bamboo Sawing Machine | 1.5kw | 58kg | 1200*500*1050 |
| 2 | Bamboo Splitting machine | 4.0kw | 650kg | 3100*700*1250 |
| 3 | Bamboo Fixed Width and Thickness Machine | 9.5kw | 550kg | 1300*650*1030 |
| 4 | Bamboo Filament Set-Size Sawing Machine | 0.75kw | 80kg | 1400*660*880 |
Working Video of Automatic Bamboo Flat Plate Machine
2. CNC Round Bamboo Toothbrush Handle Forming Machine
Automatic Round Bamboo Tooth Brush Handle Making Machine is used to form the round shape bamboo toothbrush. It adopts the CNC control system to process bamboo sticks to brush handle. This machine can work 24hour continuous working, which is stable. One worker can operate 10 units machine.
Specification of Bamboo Round Tooth Brush Handle Machine
- Capacity: 120pcs/min
- Working 24hour
- One Worker can operate 10unit
Working Video of Round Bamboo Tooth Brush Handle Machine
3. Automatic Bamboo Toothbrush Handle Hole Drilling Machine
Automatic Bamboo Tooth Brush Handle Hole Drilling Machine is used to drill hole on the toothbrush handle. It designed with four mold positions which can allow the worker to put four pieces of toothbrush handle one time. During working, Machine will drill hole on two toothbrush handles which will allow the worker to take out drilled toothbrushes handle and put the undrilled toothbrush handle on another two toothbrush position.
Specification of Bamboo Tooth Brush Handle Hole Drilling Machine
| Model | RM-THD20 |
| Power | 0.37 KW |
| X-Axis Motor Power | 400W Servo Motor |
| Y-Axis MotorPower | 400W Servo Motor |
| Drill Shaft Speed | 10000RPM |
| Dimension | 1000*820*1230mm |
| Weight | 450KG |
| Output | 6 seconds per unit |
Working Video of Bamboo Toothbrush Machine
4. Bamboo Toothbrush Hair Planting Machine
Automatic Bamboo Tooth Brush Hair Planting Machine is used to add hair on the handle.
Specification of Bamboo Tooth Brush Hair Planting Machine
| Model | RM-BHP760 |
| Compressed Air | 0.4~0.5MPa |
| Speed | 760hole/min |
| Hair Length | 10~15mm |
| Hole Size | 1.6~3 |
| Power | 2.2KW (MAX) |
| Weight | 900Kg |
Working Video of Tooth Brush Hair Planting Machine
Company Profile
Romiter Machinery Co., Ltd. is a market-leading designer and a manufacturer of brush machinery. we focused on researching and designing the machinery for different types of brush manufacture solutions. Now, Our factory can provide wooden paint brush handle forming machine, automatic wooden brush ferrule nailing machine, Wooden Brush Handle Round Forming Machine, Wooden Paint Brush Handle Surface Shaving Machine, Wooden Brush Handle Hole Drilling Machine, Paint Brush Wooden Handle Sanding Machine, Brush Bristle Mixing Machine, Brush Ferrule Bristle Filling Machine, cosmetic wooden brush handle machine, Paint Roller Frame Handle Making Machine, Paint Roller Brush Making Machine, Paint Roller Frame Cage Assembling Machine, paint roller frame handle assembling machine, toothbrush making machine and brush metal ferrule making machine.
Romiter Brush Processing Machine meets Europe Quality Requirement. with CE Certification
Welcome to contact us for more information.
