Full Automatic Paint Brush Metal Ferrule Making Machine is used to make metal ferrule. We can change mold for different size paintbrush metal ferrule. It automatic complete steel belt feeding, steel belt punching cutting, steel belt logo punching and metal ferrule bending forming. According to customer requirements, we can make different logos and size molds. This is one idea Brush Ferrule Manufacturing Equipment.
Paint Brush Metal Ferrule Steel Belt Material
Mold for Paint Brush Metal Ferrule Making Machine
Specification of Paint Brush Metal Ferrule Making Machine
- Model: RM-FM35
- Voltage: 380v,3.7kw/hour
- Operating Control Mode : PLC and Pneumatic
- Steel Plate Cutting Machine: 1.45m*0.9
- Ferrule Forming Machine: 1m*0.89m
- Capacity : 35pcs/min
- Product Size Range:0.5″-6″
Delivery Packing List for Paint Brush Metal Ferrule Making Machine
Packing List for 25TON Punching Machine Metal Ferrule Line | ||||
Item | Name | Dimension | Volume | Weight |
1 | 25ton Punching Machine | 2.2×1.1×1.3m | 3.15m3 | 2000kg |
2 | Forming Machine and Mould | 0.95×0.95×1.50m | 1.35m3 | 450kg |
3 | Control Cabinet | 0.52×0.52×1.22m | 0.33m3 | 55kg |
4 | Feeding Device | 0.88×0.8×1.22m | 0.86m3 | 190kg |
5 | Punching Machine Parts | 0.81×0.45×0.53m | 0.19m3 | 43kg |
Total | 5.88m3 | 2738kg |
Working Video of Paint Brush Metal Ferrule Making Machine
Company Profile
Romiter Machinery Co., Ltd. is a market-leading designer and a manufacturer of brush machinery. we focused on researching and designing the machinery for different types of brush manufacture solutions. Now, Our factory can provide wooden paint brush handle forming machine, automatic wooden brush ferrule nailing machine, Wooden Brush Handle Round Forming Machine, Wooden Paint Brush Handle Surface Shaving Machine, Wooden Brush Handle Hole Drilling Machine, Paint Brush Wooden Handle Sanding Machine, Brush Bristle Mixing Machine, Brush Ferrule Bristle Filling Machine, cosmetic wooden brush handle machine, Paint Roller Frame Handle Making Machine, Paint Roller Brush Making Machine, Paint Roller Frame Cage Assembling Machine, paint roller frame handle assembling machine, toothbrush making machine and brush metal ferrule making machine.
Romiter Brush Processing Machine meets Europe Quality Requirement. with CE Certification
Welcome to contact us for more information.
